Forged Steel Globe Valve

Next > >

<< Previous

Send Inquiry

Product Code : CLASS-800-1500-2500

Brand Name : Oventrop

Price And Quantity

Minimum Order Quantity
1 Piece
Price
1000 INR

Product Specifications

Product Type
Forged Globe Valve
Color
Grey and Blue

Material
Steel
Pressure
High Pressure

Media
Water
Working Temperature
Medium

Surface
Painted

Product Description

Over a long period of time, we have emerged as an eminent manufacturer of a huge assortment of Forged Steel Gate Valve. Our offered valves are designed and manufactured keeping in mind all the set industrial standards and by making use of superior grade steel metal which is procured from certified sources in the industry. In addition to this, our range of Forged Steel Gate Valve is best acclaimed for features like dimensional accuracy, precisely designed, sturdy construction and many more. We have made it available in various sizes and shapes.

FEATURES

OS & Y type , bolted bonnet
Design std:API 602/ANSI B 16.34, Testing as per API 598
Low operating torque
Valves with back seat arrangement
Solid Wedge
Deep stuffing box to accommodate more packing rings
Screwed to BSP as per BS21/ASNI/ASME B 1.20 NPT/Sockets weld to B16.11/Buttweld ends as per B 16.25

ON REQUEST

API 6D Design
Full bore construction
Extended bonnet for cryogenis service
Locking arrangement
NACE as per MR-01-75
Welded bonnet
Stellited / Hard Faces

PLEASE CONSULT US FOR

High temp. / cryogenic service
Other Material
Other Trim Material

MATERIAL OF CONCLUSION

BODY: A105/A182 Gr.304/316

BONNET: A105/A182 Gr.304/316

GASKET: sp. wound ss304/316 with Graphite/ PTFE Filter

GLAND PACKING: Graphoil/ PTFE

WEDGE FACING: 13%cr./SS304/316

SEAT: 13%cr./SS304/316

STEM: F6/304/316

GLAND BUSH: A 105/suitable to body material

GLAND FLANGE: forged steel

YOLK SLEEVE: A 439-D2/AL.BRONZE

HAND WHEEL: Malleable iron / Cast steel

All Fasteners are as per A193 Gr. B7 / A194 Gr. 2H. Other grades on request

Trade Information

Payment Terms
Telegraphic Transfer (T/T), Cash in Advance (CID), Cash Advance (CA)
Supply Ability
100 Piece Per Day

Delivery Time
15-30 Days
Main Export Market(s)
Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
